API 5L X46 Pipe
Grades:X46
Level:PSL1,PSL2
Outer Diameter: 1/2"-80"
Thickness:SCH10-SCH160
Fastest Delivery Time: 7 Days+
Related Certificates: API 5L Certificate,ISO Certificate,QMS Certificate...
Introduction of API 5L X46 Pipe:
|
Product Name |
API 5L X46 Pipe |
|
Standard and Grade |
API 5L X46 PSL1, PSL2 |
|
Welding Type |
ERW(Electrical Resistance Weld), HFW(High Frequency Weld), LSAW(Longitudinally Submerged Arc Welding), DSAW(Double Submerged Arc Welding), SSAW(Spirally Submerged Arc Welding) |
|
Outer Diameter |
1/2"-80" (21.3mm--2032mm) |
|
Thickness |
SCH10-SCH160 (6.35mm-59.54mm) |
|
Length |
6m-18m |
|
End |
BE(Beveled Ends), PE(Plain Ends) |
|
Test |
Chemical Component Analysis, Mechanical Properties (Tensile strength, Yield strength, Elongation), Ultrasonic Testing, NDT(nondestructive testing), Hydrostatic Test, X-ray Test |
|
Fastest Delivery Time |
7 Days for normal specification |
|
|
|
|
Outer Diameter |
Norminal Wall Thickness(mm) |
|||
|
INCH |
MM |
|||
|
1/2-80 |
21.3-2032 |
6.35-59.54 |
||
|
Steel Grade |
Chemical Composition % |
|||||
|
API 5L X46(PSL1)
|
C max |
Mn max |
P max |
S max |
Ti max |
Others |
|
0.28 |
1.40 |
0.030 |
0.030 |
0.04 |
b,c |
|
|
API 5L X46(PSL2) |
0.24 |
1.40 |
0.025 |
0.015 |
0.04 |
b,c |
a. Nb+V≤0.03%
b. According to the manufacturer's choice, Nb, V, or their combination can be added.
c. Nb+V+Ti≤0.15%
d. Nb+V≤0.06%
Mechanical Properties:
|
Steel Grade |
Tensile Strength Mpa |
Yield Strength Mpa |
Elongation (%) |
|
API 5L X46(PSL1) |
434 min |
317 min |
_ |
|
API 5L X46(PSL2) |
434-758 |
317-524 |
_ |
· Competitive Price: We have long-term stable cooperation with raw material factories, mature and complete production supporting facilities, a rigorous quality control system, and an integrated model that keeps our production costs at a relatively low level.
· Fast Delivery Time: The production of steel pipes with standard specification can be completed in as fast as 7 days.
· Complete Certification: All types of certificates are available, including API 5L certificate, ISO 9001 certificate, ISO 14001 certificate, FPC certificate, Environmental Quality System certificate, and more.
· Advanced Production Equipment: We imported the equipment from Germany and developed independently four production equipments.
· Professional Team: We have over 300 employees, including more than 60 technical personnel, and possesses an independent equipment research team.
· Comprehensive Testing Facilities: We are equipped with various testing facilities, including but not limited to online ultrasonic automatic flaw detectors, industrial X-ray television and other essential testing equipment.
Application:
Longma Group's API 5L X46 Pipe find wide-ranging applications in:
|
|
|
|
Oil and gas pipelines |
Structural support for bridge, building construction |
|
|
|
|
Water and liquid transportation |
Piling and foundation work in construction project |
|
|
|
|
Offshore/Onshore construction |
Electricity and Heating power |
Hebei Longma Group Limited(LONGMA GROUP) is one of China leading ERW/LSAW steel pipe manufacturers since 2003, with a registered capital of 441.8 billion, covering an area of 230000 square meters. The company specializes in the production: large-diameter, thick-walled, double-sided, sub-arc-seam, welding steel pipe, LSAW-Longitudinal Submerged Arc Welded, ERW steel pipes. By the end of 2023, the company's annual output exceeded 1000000 tons. For inquiries or assistance, please contact us at info@longma-group.com, and let us partner with you in building a better future through resilient pipeline solutions.
|
|
|
|
FAQ:
Q：What is API 5L X46 Pipe?
A：API 5L X46 Pipe is a high-quality steel pipe manufactured according to API standards for use in conveying gas, water, and oil in various industries.
Q：What are the key features of API 5L X46 Pipe?
A：API 5L X46 Pipe boasts superior corrosion resistance, high strength, and excellent mechanical properties, making it ideal for demanding applications.
Q：What sizes are available for API 5L X46 Pipe?
A：Longma offers API 5L X46 Pipe in a wide range of sizes, from 1/8" to 48" nominal diameter, to meet the diverse needs of our customers.
Q：What are the typical applications of API 5L X46 Pipe?
A：API 5L X46 Pipe finds application in the oil and gas industry, petrochemical sector, construction projects, and water supply systems, among others.
