API 5L X80 Pipe
Grades:X80
Level:PSL1,PSL2
Outer Diameter: 1/2"-72"
Thickness:SCH10-SCH160
Fastest Delivery Time: 7 Days+
Related Certificates: API 5L Certificate,ISO Certificate,QMS Certificate...
Introduction of API 5L X80 Pipe:
|
Product Name |
API 5L X80 Pipe |
|
Standard and Grade |
API 5L X80 PSL1, PSL2 |
|
Welding Type |
ERW(Electrical Resistance Weld), HFW(High Frequency Weld), LSAW(Longitudinally Submerged Arc Welding), DSAW(Double Submerged Arc Welding), SSAW(Spirally Submerged Arc Welding) |
|
Outer Diameter |
1/2"-80" (21.3mm--2032mm) |
|
Thickness |
SCH10-SCH160 (6.35mm-59.54mm) |
|
Length |
6m-18m |
|
End |
BE(Beveled Ends), PE(Plain Ends) |
|
Test |
Chemical Component Analysis, Mechanical Properties (Tensile strength, Yield strength, Elongation), Ultrasonic Testing, NDT(nondestructive testing), Hydrostatic Test, X-ray Test |
|
Fastest Delivery Time |
7 Days for normal specification |
|
|
|
API 5L X80 Pipe Specification:
|
Outer Diameter |
Norminal Wall Thickness(mm) |
|||
|
INCH |
MM |
|||
|
1/2-80 |
21.3-2032 |
6.35-59.54 |
||
Chemical Composition:
|
Steel Grade |
Chemical Composition % |
|||||
|
API 5L X80(PSL1) |
C max |
Mn max |
P max |
S max |
Ti max |
Others |
|
0.28 |
1.40 |
0.030 |
0.030 |
0.06 |
b,c |
|
|
API 5L X80(PSL2) |
0.24 |
1.40 |
0.025 |
0.015 |
0.06 |
b,c |
a. Nb+V≤0.03%
b. According to the manufacturer's choice, Nb, V, or their combination can be added.
c. Nb+V+Ti≤0.15%
Nb+V≤0.06%
Mechanical Properties:
|
Steel Grade |
Tensile Strength Mpa |
Yield Strength Mpa |
Elongation (%) |
|
API 5L X80(PSL1) |
621 min |
552 min |
_ |
|
API 5L X80(PSL2) |
621-827 |
552-690 |
_ |
Our Advantages for API 5L X80 Pipe:
· Competitive Price: We have long-term stable cooperation with raw material factories, mature and complete production supporting facilities, a rigorous quality control system, and an integrated model that keeps our production costs at a relatively low level.
· Fast Delivery Time: The production of steel pipes with standard specification can be completed in as fast as 7 days.
· Complete Certification: All types of certificates are available, including API 5L certificate, ISO 9001 certificate, ISO 14001 certificate, FPC certificate, Environmental Quality System certificate, and more.
· Advanced Production Equipment: We imported the equipment from Germany and developed independently four production equipments.
· Professional Team: We have over 300 employees, including more than 60 technical personnel, and possesses an independent equipment research team.
· Comprehensive Testing Facilities: We are equipped with various testing facilities, including but not limited to online ultrasonic automatic flaw detectors, industrial X-ray television and other essential testing equipment.
Application:
Longma Group's API 5L X80 Pipe find wide-ranging applications in:
|
|
|
|
Oil and gas pipelines |
Structural support for bridge, building construction |
|
|
|
|
Water and liquid transportation |
Piling and foundation work in construction project |
|
|
|
|
Offshore/Onshore construction |
Electricity and Heating power |
Longma Group:
Hebei Longma Group Limited(LONGMA GROUP) is one of China leading ERW/LSAW steel pipe manufacturers since 2003, with a registered capital of 441.8 billion, covering an area of 230000 square meters. The company specializes in the production: large-diameter, thick-walled, double-sided, sub-arc-seam, welding steel pipe, LSAW-Longitudinal Submerged Arc Welded, ERW steel pipes. By the end of 2023, the company's annual output exceeded 1000000 tons.
|
|
|
|
Contact Us:
For inquiries or to place an order, please contact us at info@longma-group.com. Experience the difference with Longma Group and elevate your industrial infrastructure to new heights with the API 5L X80 Pipe.
FAQ:
Q: What distinguishes the API 5L X80 Pipe from other piping solutions?
A: The API 5L X80 Pipe offers unparalleled strength, durability, and corrosion resistance, making it the preferred choice for demanding industrial applications.
Q: Can the API 5L X80 Pipe be customized to meet specific project requirements?
A: Yes, Longma offers customization options to tailor the API 5L X80 Pipe to your exact specifications, ensuring optimal performance and efficiency.
Q: Is the API 5L X80 Pipe suitable for use in high-pressure environments?
A: Absolutely, our pipes are designed to withstand high-pressure and high-temperature conditions, making them ideal for critical applications in oil and gas transmission and beyond.
Q: What is the typical lead time for API 5L X80 Pipe orders?
A: Longma is committed to fast delivery, with most orders fulfilled within the shortest possible time frame to meet your project deadlines.
